Brake Endurance Test Bench

Brake Endurance Test Bench manufacturers & exporters from India, Brake Endurance Test Bench is designed for Endurance testing of Railway Brake Main Features of the Test Bench are:

  •  PC based system with Lab VIEW software & NI data acquisition cards for measuring process parameters.
  •  Safety chamber with Aluminum profile & polycarbonate cover
  •  Hydraulic power Pack & hydraulic cylinder with load cell to simulate real load test conditions for components under test.
  •  Pneumatic power Pack to simulate real operation of brake working test conditions for components under test.
  •  Pneumatic power pack with Electro Prop Valve for controlling test pressure up to 0 – 8 Kf/cm2, pressure store using Auxiliary Reservoir.
  •  Pressure from Auxiliary Reservoir for brake testing acquired, displayed and controlled under set time and pressure limits for different models.
  •  Components are put under test for settable number of cycles normally ranging up to 1, 00,000 & above.
  •  Data logging of Parameter for analysis
